Numerical Shape Optimization of Photoacoustic Sample Cells: First Results

B. Baumann1, B. Kost1, M. Wolff1,2, H. Groninga2, T. Blöß1, and S. Knickrehm1
1Hamburg University of Applied Sciences, Hamburg, Germany
2PAS-Tech GmbH, Zarrentin, Germany

First results in the automatic shape optimization of a photoacoustic sample cell are described. The aim is to maximize the sensor’s signal strength. The approach considers all shapes that can be represented by a number of axis-symmetrical truncated cones which are connected in a continuous way. In addition, the cell is subjected to certain constraints (e.g. the laser beam is not blocked during ...

Numerical Study on Acoustic Field Generated by Dipole Sources in Noncircular Pipe

H. Zhang, W. Lin, and X. Wang
Chinese Academy of Sciences, Institute of Acoustics, Beijing, China

Acoustical well logging is an important technology for petroleum industry. Calibration and testing of tools in real wells is not feasible because the cost is high and the condition is not controllable. During manufacturing and maintaining, the logging tools are usually tested in a fluid filled circular pipe. The acoustic field in non-circular wells are calculated by using of the PDE mode of ...

Two- and Three-Dimensional Holey Phononic Crystals with Unit Cells of Resonators

Y.F. Wang[1][2], Y.S. Wang[1], L. Wang[2]
[1]Institute of Engineering Mechanics, Beijing Jiaotong University, Beijing, China
[2]Department of Mechanical Engineering, Østfold University College, Halden, Norway

We show in this paper that by careful design of the geometry of the resonators, complete bandgap with relatively low center frequency can be obtained for 2D and 3D Phononic Crystals with resonators. The generation of the bandgap is due to the local resonance of the unit cell. Spring-mass and spring-pendulum models are developed to predict the boundaries of the complete bandgap. The predicted ...

Towards Rotordynamic Analysis with COMSOL Multiphysics

M. Karlsson[1]
[1]ÅF, Stockholm, Sweden

In this paper a pre-study on using COMSOL Multiphysics for rotordynamic analysis is presented. It is concluded that it is possible to use COMSOL Multiphysics to perform rotordynamical analysis. However, there are no standard environment for rotordynamics, hence the user has to extend the structural model with the rotordynamics effect such as gyroscopic effect and rotordynamical coefficients. By ...

A Study of FEMLAB for Modeling High Frequency Ultrasound Scattering by Spherical Objects

Falou, O.1, Kumaradas, J.C.2, Kolios, M.C.3 1 Dept. of Electrical and Computer Engineering, Ryerson University, ON, Canada
2 Dept. of Electrical and Computer Engineering & Dept. of Physics, Ryerson University, ON, Canada
3 Dept. of Physics, Ryerson University, ON, Canada

Analytical solutions to the problem of wave scattering from three dimensional structures such as spheres have been studied extensively in the past. However, these solutions are not flexible enough to be extended to wave scattering from complex geometries. We have developed a finite element model of acoustic wave propagation through spherical structures to solve the problem of highfrequency (20 ...

Towards a Finite Element Calculation of Acoustical Amplitudes in HID Lamps

B. Baumann[1], M. Wolff[1], J. Hirsch[2], P. Antonis[2], S. Bhosle[3], and R. Valdivia Barrientos[4]
[1]Hamburg University of Applied Sciences, Hamburg, Germany
[2]Philips Lighting, Eindhoven, The Netherlands
[3]LAPLACE, Université de Toulouse and CNRS, Toulouse, France
[4]National Institute of Nuclear Research, Salazar, Ocoyoacac, Mexico

High intensity discharge lamps can experience flickering and even destruction, when operated at high frequency alternating current. The cause of these problems has been identified as acoustic resonances inside the lamp’s are tube. Here, a finite element approach for the calculation of the acoustic response function is described. The developed model does not include the plasma dynamics.

Simulation and Evaluation of Small High-Frequency Side Scan Sonars Using COMSOL

J. Jonsson[1], E. Edqvist[1], H. Kratz[1], M. Almqvist[2], and G. Thornell[1]
[1]Ångström Space Technology Centre, Uppsala University, Uppsala, Sweden
[2]Department of Measurement Technology and Industrial Electrical Engineering, Lund University, Lund, Sweden

High frequency side-scan sonar, to be fitted on a miniaturized submersible explorer, have been simulated and built. The purpose of this study is to see if COMSOL Multiphysics® can be used to predict the performance of the sonar, especially the beam width, setting the resolution of the system. Four models were created, from simple 2-D geometries to more complex 3-D models. The simulated beam ...

Structured Ultrasonic Metasurfaces

R. C. Thiagarajan
ATOA Scientific Technologies Private Limited
Bangalore, India

Ultrasonic acoustic waves usually encounter interfaces with significant impedance mismatch in practical medical or industrial imaging applications. A transparent interface can help to improve the performance of medical and industrial imaging and overall innovative applications. Similarly, a broadband total reflection interface can help to improve the architectural or transportation barrier ...

Modeling of a Jecklin Disk for Stereophonic Recordings

G. McRobbie[1]
[1]University of the West of Scotland, Paisley, Renfrewshire, UK

The Jecklin Disk is a sound absorbing disk placed between two omnidirectional microphones. It is used to recreate some of the frequency-response, time and amplitude variations human listeners’ experience, but in such a way that the recordings also produce a useable stereo image through loudspeakers. This paper presents a finite element model able to simulate the effects on sound propagation ...

Innovating New Products using Multiphysics Modeling


Dr. Shekhawat is currently the General Manager for New Products Development at Secure Meters Ltd., Udaipur. Prior to this, he was with CEERI, Pilani for 23 years. He has a Ph.D., MS, M. Sc. (Physics) and BE (EEE) from BITS, Pilani. He is the recipient of several honours including the DAAD Fellowship, Germany and National Science Talent Fellowship. His areas of research include Ultrasonic ...
