Technical Papers and Presentations

Here you will find presentations given at COMSOL Conferences around the globe. The presentations explore the innovative research and products designed by your peers using COMSOL Multiphysics. Research topics span a wide array of industries and application areas, including the electrical, mechanical, fluid, and chemical disciplines. Use the Quick Search to find presentations pertaining to your application area.

Simulation of Acoustic Energy Harvesting Using Piezoelectric Plates in a Quarter-Wavelength Straight-Tube Resonator

B. Li[1], J.H. You[1]
[1]Southern Methodist University, Dallas, TX, USA

An acoustic energy harvesting mechanism at low frequency (~200 Hz) using lead zirconate titanate (PZT) piezoelectric cantilever plates placed inside a quarter-wavelength straight-tube resonator has been studied using COMSOL Multiphysics 4.3 and compared with experimental data. When the tube resonator is excited by an incident wave at its acoustic eigenfrequency, an amplified acoustic resonant ...

Acoustic Field Comparison of High Intensity Focused Ultrasound Using Experimental Characterization and Finite Element Simulation

J. L. Teja[1], A. Vera[1], L. Leija[1]
[1]Department of Electrical Engineering, Cinvestav-IPN, Mexico D.F., Mexico

High Intensity Focused Ultrasound (HIFU) is used as a noninvasive technique of tissue heating and ablation for different medical treatments. This paper presents a quantitative comparison of HIFU acoustic fields experimentally obtained versus simulated acoustic fields. Acoustic field characterization was realized in two HIFU transducers using water as a propagation medium. Also, simulations were ...

Effects of Fluid and Structural Forces on the Dynamic Performance of High Speed Rotating Impellers.

C. Thiagarajan[1], G. Shenoy[2], B. S. Shenoy[3]
[1]ATOA Scientific Technologies Pvt Ltd, Whitefield, Bangalore, India.
[2]Department of Mechanical & Manufacturing Engineering, Manipal Institute of technology, Manipal, India
[3]Department of Aeronautical & Automobile Engineering, Manipal Institute of Technology, Manipal, India

Vibration and Dynamic performances of the rotating machinery are conventionally evaluated based on the dominant structural forces such as the centrifugal forces. The increase in rotational speed, miniaturization and performance, demands for improved and accurate evaluation of the vibration performance. The inclusion of coupled effects of fluid and centrifugal forces can contribute significantly ...

An Investigation of Loudspeaker Simulation Efficiency and Accuracy Using i) A Conventional Model, ii) The Near-To-Far-Field Transformation and iii) The Rayleigh Integral

R. Christensen[1], U. Skov[1]
[1] iCapture ApS, Roskilde, Denmark

Simulation on loudspeaker drivers require a conventional fully coupled vibro-acoustic model to capture all effect. An accurate vibroacoustic model can be time-consuming to solve, especially in 3D. In practical applications, this results in poor efficiency concerning the decision-making process to move on to the next simulation model. To overcome this the loudspeaker designer can use either the ...

Improved Perfectly Matched Layers for Acoustic Radiation and Scattering Problems

M. Zampolli[1], N. Malm[2], and A. Tesei[1]
[1]NURC NATO Research Centre, La Spezia, Italy
[2]COMSOL AB, Stockholm, Sweden

Perfectly matched layers (PML) are an efficient alternative for emulating the Sommerfeld radiation condition in the numerical solution of wave radiation and scattering problems. The key ingredient of the PML formulation is the complex scaling function, which controls the anisotropic damping of the PML. The objective of this study is to propose a modified complex scaling function capable of ...

3-D Finite Element Modeling of a Nanostructure Enhanced SAW Sensor

Y.L. Rao[1], and G. Zhang[1-3]
[1] Micro/Nano Bioengineering Laboratory, Department of Biological and Agricultural Engineering, The University of Georgia
[2] Nanoscale Science and Engineering Center, The University of Georgia
[3] Faculty of Engineering, The University of Georgia

Integration of surface acoustic wave (SAW) devices with nanostructures has gained interest in the development of sensors with high sensitivity. To better design nanostructure integrated SAW devices, it is essential to model three dimensional (3-D) SAW devices and analyze the wave propagation characteristics in nanostructure-enhanced SAW devices. In this work, a 3-D finite element model of ...

Investigation on Sensor Fault Effects of Piezoelectric Transducers on Wave Propagation and Impedance Measurements

I. Buethe[1], C.-P. Fritzen[1]
[1]University of Siegen, Institute of Mechanics and Control Engineering-Mechatronics, Siegen, Germany

For active Structural Health Monitoring (SHM), one popular sensor type is the piezoelectric wafer active sensor (PWAS) due to its multi-purpose application as actuator and sensor and its low cost. It is used to generate a wave field, which interacts with the structure and is recorded by a second set of PWASs. This method is called acousto ultrasonics. The change in wave field from transducer ...

High-Intensity Piezo-Ceramic Ultrasonic Transducer with Mechanical Amplifier and Radiation Plate

A. van Wijhe[1], W. de Jong[1]
[1]Process & Energy, 3mE, TU Delft, The Netherlands

A COMSOL Multiphysics® model was made to design a mechanical amplifier and radiation plate for the emission of high intensity 40.5 kHz ultrasound to air by means of a Langevin type transducer usually applied in cleaning baths for example. In this work, ultrasonic irradiation is aimed at acting on flue gas containing fine particulate matter to realize a shift to higher effective particle sizes as ...

Analysis of Acoustic Response of Rooms

J.S. Crompton[1], L.T. Gritter[1], S. Yushanov[1], K.C. Koppenhoefer[1], and D. Magyari[2]
[1]AltaSim Technologies, LLC, Columbus, OH, USA
[2]Golden Acoustics, Detroit, MI, USA

The preferred acoustic response of recording studios, auditoriums and conference halls is to have an even energy response over the entire room and throughout full audio spectrum. This can be accomplished by using acoustic panels with complex surface structures that scatter acoustic waves and diffuse sound level variability over the room volume or through the use of sound absorbing materials to ...

Harmonic Simulation of Viscoelastic Polymer Microcantilever for Electrostrictive Energy Harvesters

N. Alcheikh[1], C. Ayela[1], I. Dufour[1]
[1]Univ. Bordeaux, IMS Lab, Pessac, France.

Electrostrictive polymers have been of significant interest over the last years for energy harvesting. Principle is based on the conversion of a mechanical deformation into electricity. The stored energy basically depends on the mechanical strain induced into an electrostrictive polymer by the mechanical resonant vibration of a microcantilever supporting the electrostrictive layer. In this work, ...
