A. Secchi, V. Foglietti, E. Cianci, L. Pierno, and M. Dispenza
 CNR-IFN, Italy
 SELEX-SI, Italy
The subject of this work is the design of a LiNbO3 electro-optic tuned Bragg filter to be used as an amplitude modulator. We analyze in detail the realized waveguide and simulate the grating, developing a fabrication methodology for building the Bragg modulator by niobate core etching. Finally, we evaluate the performance of the modulator, using the finite element method analysis.
I. Ponomarev 1, M. Bayer2, and T. Reinecke1
1Naval Research Laboratory, Washington, DC, USA
2Universität Dortmund, Dortmund, Germany
The influence of disorder on the optical mode spectrum of chains of coupled micron-sized microcavities has been studied both experimentally and theoretically with the help of COMSOL. The disorder is introduced by systematic variation of cavity sizes. The resulting spectra are interpreted in terms of modified dispersion for propagation along the chains accompanied by the appearance of localized ...
Mathematics Department, University of California, Los Angeles, CA, USA
We present an optimization procedure to optimize the maximum coupling of free space optical wave to surface plasmon. Shape derivative from shape sensitivity analysis is calculated, and the corresponding partial derivatives of the objective functional with respect to finite number of design variables are derived. An optimal design of the gratings to couple maximum amount of free space photon into ...
Fibre-Optic Microsensor Based on Surface Plasmon Resonance in a Microfluidic Cell : An Experimental and Numerical Multiphysics Approach
G. Louarn, T. Makiabadi, V. Le Nader, and M. Kanso
Institut des Matériaux Jean-Rouxel (IMN), CNRS- Université de Nantes, France
In the last decade, the surface plasmon resonance (SPR) has become a very sensitive technique for real-time detection in many application areas. Considering the fiber optic concept and the important needs for analyzing biomolecular reactions through automated and miniaturized components, fiber optic sensors based on the SPR technique are becoming an important choice in the field of sensing. In ...
Determination of the Optical Properties of Individual Gold Nanorods through Numerical Modeling and Experiment
Y. Davletshin, J.C. Kumaradas
Ryerson University, Toronto, ON, Canada
The optical scattering and absorption of gold nanorods (GNRs) depends on its size, shape, and surroundings. This dependence is due to both intrinsic and extrinsic effects. A good understanding of this dependence is needed for applications of GNRs in photo-thermal therapy, optical and opto-acoustic imaging, biosensing, and other photonic areas. Extrinsic effects are caused by the production of ...
M. Gonçalves, O. Marti
Ulm University - Inst. of Experimental Physics, Ulm, Germany
Plasmonic resonances arising in gold nanoparticles lead to strongly localized near-field enhancements. These enhancements generate strong field gradients that can be exploited in particle trapping. On the other hand plasmonic resonances lead to enhanced absorption and heat generation. Gold nanoparticles have been used to kill cancer cells based on plasmonic heating. We have investigated the ...
FE Modeling of Surfaces with Realistic 3D Roughness: Roughness Effects in Optics of Plasmonic Nanoantennas
J. Borneman, A. Kildishev, K. Chen, and V. Drachev
School of Electrical and Computer Engineering and Birck Nanotechnology Center, Purdue University, West Lafayette, Indiana, USA
COMSOL Multiphysics has been widely used to model the near and far-field electromagnetics (specifically, transmission and reflection spectra) of gold and silver nanoantenna arrays. We use a moving 3D mesh, thus preserving the DOF number and simply morphing the structure of the mesh to accommodate the moving boundary. The electromagnetics model consist of four multiphysics models, two ...
F. Dell’Olio, F. De Leonardis, and V.M.N. Passaro
Politecnico di Bari
One of the most important requirements of any integrated optical technology is the ability to perform optical modulation, which permits to encode a bit stream onto the optical carrier provided by the laser source. In this paper a multiphysics model for silicon modulators adopting a Metal Oxide Semiconductor (MOS) structure is presented.
An Efficient Approach to Identifying a Complete Photonic Band Gap in Two-dimensional Photonic Crystals with Omnidirectional Light Propagation
R. F. Jao1,2, and M.-C. Lin1
1NanoScience Simulation Laboratory, Department of Physics, Fu Jen Catholic University, Taipei County, Taiwan
2Department of Physics, National Cheng Kung University, Tainan, Taiwan
Omnidirectional light propagation in two-dimensional (2D) photonic crystals (PCs) is investigated. An efficient approach to identifying a complete photonic band gap (PBG) in 2D PCs has been developed. The in-plane band structure of 2D photonic crystals is calculated by an adaptive finite element method, as implemented in COMSOL. By adopting the suitable boundary conditions, the eigenvalues can be ...
Optimization of a Photonic Crystal Waveguide Termination using the Geometry Projection Method and COMSOL
W. R. Frei
COMSOL, Inc., Burlington, MA, USA
Using nonlinear programming, the shape of a set of dielectric rods surrounding the termination of a photonic crystal waveguide is optimized to increase the directional emission. The Geometry Projection Method (GPM) is used to define the shape of the dielectric rods around the termination of a waveguide in a square lattice rods-in-air photonic crystal. GPM uses a set of control points in a higher ...
