Modeling of III-Nitride Quantum Wells with Arbitrary Crystallographic Orientation for Nitride-Based Photonics
M. Kisin, R. Brown, and H. El-Ghoroury
Ostendo Technologies, Inc., Carlsbad, CA, USA
A program for self-consistent modeling of electron-hole energy spectrum and space-charge distribution in III-nitride based quantum well (QW) structures has been developed. The model takes into consideration full 6-band description of the valence band states, nonparabolicity of the electron spectrum, quantum confinement of electrons and holes, strain induced modifications of the band structure, ...
A. Coll, V. Di Virgilio, S. Bermejo, and L. Castañer
Universitat Politècnica de Catalunya, Barcelona, Spain
Photonic crystals are widely used in optical applications as waveguides and band filters. Filling the periodic structural material of photonic crystals with other materials is very useful in order to change the optical properties of the devices. In this paper electrostatic COMSOL simulations describing an electrospray deposition of particles in macroporous structures are performed.
M. Goncalves, T. Makaryan, G. Papageorgiou, U. Herr, and O. Marti
Ulm University - Inst. of Experimental Physics, Ulm, Germany
Yerevan State University, Yerevan, Armenia
Ulm University - Institute of Micro and Nanomaterials, Ulm, Germany
Surface enhanced Raman scattering (SERS) investigations of silver and gold triangular nanoparticles reveal strong field enhancements at the corners of the particles. Though the measurements were done at wavelengths far from the surface-plasmon resonance of the particles, large field enhancements can be generated by near-field coupling between the triangular particles and smaller metal ...
A. Alabastri, R. Krahne, A. Giugni, G. Das, R. P. Zaccaria, M. Zanella, I. Franchini, and E. di Fabrizio
Italian Institute of Technology (IIT)
We studied the optical phonon excitations (LO) of ordered arrays of dot/ rod core-shell CdSe/ CdS nanorods by Raman spectroscopy. Upon deposition on planar substrates the nanorods formed super-lattice structures via side-by side assembly into tracks over some microns of length. COMSOL Multiphysics software has been used to calculate the magnitude of the electric field generated by the ...
N. Basumallick, A. Ghosh, P. Biswas, K. Dasgupta, S. Bandyopadhyay
Fiber Optics Laboratory, Central Glass and Ceramic Research Institute, Kolkata, West Bengal, India
Sensitivity of a cantilever-mass based fiber Bragg grating (FBG) accelerometer can efficiently be tailored by altering the distance between the axis of the FBG sensor to the neutral axis of the cantilever. To accomplish that in general, a backing patch is used to mount the FBG on the cantilever. Use of finite element analysis to quantify the influence of the material constant (Young’s modulus) ...
Implementation of an 2D electro-thermal model for power semiconductor devices simulation: application on gallium nitride
Benbakhti, B., Rousseau, M., De Jeager, J.C.
Generally, the power dissipation in a semiconductor device generates self-heating effect. This effect is very significant in power applications using Gallium Nitride. Taking into account heating effects enables us to understand physical phenomena observed in experiments like the low saturation velocity. In this paper, numerical simulations were carried out to study the influence of thermal ...
Cuminal, Y.1, Christol, P.2, Rodriguez, J.B2, Joullié, A.2
1 Laboratoire des Sciences des Matériaux et d’Automatique (LASMEA), Université Clermont II, UMR CNRS 6602, Aubiére, France
2 Centre d’Electronique et de Micro-optoélectronique de Montpellier (CEM2), Université de Montpellier-II, UMR CNRS 5507, Montpellier, France
Infrared photonic detectors operating in the mid infrared region find applications in pollution monitoring, high-speed infrared imaging systems and free space telecommunications. There is a need for new uncooled high performance detector systems and antimonide-based (Sb-based) semiconductor quantum structures could be an alternative of the well-established technologies. The main objective of ...
Z. Liu, X. Ni, and A. Kildishev
School of Electrical and Computer Engineering and Birck Nanotechnology Center, Purdue University, West Lafayette, Indiana, USA
Optical nanoantennas have been of great interest recently due to their ability to support a highly efficient, localized surface plasmon resonance and produce significantly enhanced and highly confined electromagnetic fields. Such enhanced local fields have many applications such as biosensors, near-fieldscanning optical microscopy (NSOM), quantum optical information processing, enhanced Raman ...
W. Raja, A. Alabastri, S. Tuccio, R. Proietti Zaccaria
Department of Nanostructures, Istituto Italiano di Tecnologia, Genova, Italy
Surface plasmon resonance (SPR) sensors proved themselves as a promising device for many kinds of applications such as optical biosensing, binding constant determinationor nanofilm thickness measurements. Here we simulate using COMSOL Multiphysics® the light-polaritons coupling for the two most commonly used SPR setups: Attenuated total reflection (Kretschmann configuration) and diffraction ...
Periodic Near-field Enhancement on Metal-Dielectric Interfacial Gratings at Optimized Azimuthal Orientation
M. Csete[1,2], X. Hu, A. Sipos, A. Szalai, A. Mathesz, and K. Berggren
Research Laboratory of Electronics, Nanostructures Laboratory, Massachusetts Institute of Technology, Massachusetts, USA
Department of Optics and Quantum Electronics, University of Szeged, Szeged, Hungary
The effect of plasmon-wavelength scaled gratings on the surface plasmon resonance is studied experimentally and theoretically. The model samples are multi-layers containing laser fabricated gratings at bimetal-polymer interfaces. Dual-angle dependent surface plasmon resonance measurements are performed illuminating the samples by monochromatic light in Kretschmann arrangement. The ...
