Image Gallery

Welcome to the COMSOL Image Gallery. The simulation images on this page are available for editors and journalists to use in appropriate articles. The phrase "Image made using COMSOL Multiphysics® software and provided courtesy of COMSOL." must appear in the vicinity of every image or at the bottom of the article.

For all other uses you must contact COMSOL directly through www.comsol.com/contact/
or by writing to .


COMSOL Version 6.0

Airplane Antenna Simulation

Airplane Antenna Simulation

The radiation pattern of a Wi-Fi antenna operating at 850 MHz, placed on the fuselage of an airplane. The model is solved with a combination of the finite element method (FEM) and boundary element method (BEM).

Balanced Armature Transducer

Balanced Armature Transducer

Multiphysics model of a balanced armature transducer used in in-ear monitors, wireless earphones, and hearing aids. This simulation couples magnetic fields with structural deformations and makes it possible for acoustics engineers to predict the device's performance to an unprecedented degree of accuracy.

Concert Hall

Concert Hall

An acoustics ray tracing simulation of a concert hall. This type of analysis can be used to predict room acoustics metrics, such as reverberation time, even before the building is constructed.

Electric Motor

Electric Motor

An electric motor simulation using COMSOL Multiphysics®, where design engineers can optimize and predict the performance of motor designs prior to building prototypes.

Hydrocyclone

Hydrocyclone

Fluid dynamics simulation of a hydrocyclone characterized by a very strong swirl and anisotropic turbulence. Cyclones are used in a variety of applications, ranging from the mining industry to vacuum cleaners.

Microwave Component

Microwave Component

COMSOL Multiphysics® version 6.0 and the RF Module provide a library of magnetic materials, which can be included in models of microwave components such as ferrite resonators and circulators.

Model Manager

Model Manager

The Model Manager in COMSOL Multiphysics provides version control and common storage for efficient collaboration in projects.

Optic Lens System

Optic Lens System

COMSOL Multiphysics® version 6.0 provides advanced visualization functionality, including realistic transparency of materials like glass, as shown in this ray optics simulation of a system of lenses.

Pasta Extrusion

Pasta Extrusion

A multiphysics model of a pasta extrusion process, taking into account the influence of temperature variations on the viscosity of the fluid.

PEM Fuel Cell

PEM Fuel Cell

A detailed electrochemical, fluid flow, and heat transfer simulation of a polymer electrolyte membrane (PEM) fuel cell. This type of fuel cell uses hydrogen as fuel and has important applications in vehicle electrification, especially with regards to extending the range of electric vehicles.

Printed Circuit Board

Printed Circuit Board

COMSOL Multiphysics version 6.0 delivers performance improvements and simplifies simulation of many important applications, such as printed circuit board (PCB) designs (pictured).

Sports Car

Sports Car

Simulation of the wind load on a sports car’s side door and mirror using the fluid–structure interaction capabilities of COMSOL Multiphysics®.

Turbine

Turbine

COMSOL Multiphysics® version 6.0 includes advanced visualization functionality, such as realistic ambient light.

Uncertainty Quantification Module

Uncertainty Quantification Module

The Uncertainty Quantification Module reveals how variability of input parameters affects the simulation results.
