Image Gallery

Welcome to the COMSOL Image Gallery. The simulation images on this page are available for editors and journalists to use in appropriate articles. The phrase "Image made using COMSOL Multiphysics® software and provided courtesy of COMSOL." must appear in the vicinity of every image or at the bottom of the article.

For all other uses you must contact COMSOL directly through www.comsol.com/contact/
or by writing to .


COMSOL Version 5.5

Thermal Distribution Energy Pack

Thermal Distribution Energy Pack

The temperature distribution in a 6s2p battery pack at the end of a 4C discharge.

Parametric Sketching with Dimensions

Parametric Sketching with Dimensions

Parametric optimization of fluid flow in a microvalve using the sketching tool with dimensions and constraints capabilities available in the Design Module.

Solver Technology for Acoustics Simulations

Solver Technology for Acoustics Simulations

Sound pressure field in a car interior solved with the finite element method at 7 kHz using a specialized solver for wave propagation analysis.

Metal Processing Module

Metal Processing Module

Residual stresses in a spur gear after quenching, calculated using the Metal Processing Module.

Porous Media Flow Module

Porous Media Flow Module

Simulation of a packed bed latent heat storage tank, using the Porous Media Flow Module.

Shape and Topology Optimization

Shape and Topology Optimization

Shape optimization of a sheet metal bracket using the Optimization Module. The structure is subjected to a bending load resulting in ridges in the optimal design.

Elastic Chain Drive Analysis

Elastic Chain Drive Analysis

Elastic chain drive analysis in the Multibody Dynamics Module. Colors and arrows show the velocity and velocity direction, in the chain and sprockets.

COMSOL Runtime™ Installer

COMSOL Runtime™ Installer

The COMSOL Runtime™ installer for efficient distribution of standalone applications created with the Application Builder and compiled with COMSOL Compiler™.
