Here you will find presentations given at COMSOL Conferences around the globe. The presentations explore the innovative research and products designed by your peers using COMSOL Multiphysics. Research topics span a wide array of industries and application areas, including the electrical, mechanical, fluid, and chemical disciplines. Use the Quick Search to find presentations pertaining to your application area.

Key-Holes Magnetron Design and Multiphysics Simulation

A. Leggieri[1], F. Di Paolo[1], D. Passi[1]
[1]Univeristy of Rome "Tor Vergata" - Department of Electronic Engineering, Rome, Italy

This paper describes the design and characterization of an 8 slots resonant cavity Magnetron, which undergoes thermal-structural effects due to cathode heating. The proposed study involves Thermal Stress, Eigen-frequency and Particle Tracing analysis based on COMSOL Multiphysics®. Magnetrons are well known and often utilized High Power Radiofrequency Vacuum Tube oscillators. In order to ...

Modeling Microwave Heating During Batch Processing of a Liquid Sample in a Single Mode Cavity

S. Curet [1], F. Bellicanta Begnini [1], O. Rouaud [1], L. Boillereaux [1]
[1] L’UNAM Université, ONIRIS, CNRS, GEPEA, Nantes, France

The use of microwaves for heating purposes of dielectric materials is encountered in many industrial applications (food processing, chemistry, material engineering and medical applications). In most of these thermal applications, the prediction of the temperature evolution within the processed materials is of primary interest in order to optimize the treatment (Chandrasekaran et al., 2013). In ...

Virtual Prototype of a Dielectric Window for High-Power Microwave Tubes - new

A. Leggieri[1], D. Passi[1], F. di Paolo[1]
[1]Dipartimento di Ingegneria Elettronica, Università degli Studi di Roma Tor Vergata, Rome, Italy

This paper describes the Virtual Prototype of a Dielectric Window or High Power Microwave Vacuum Tubes and Linear Accelerators. Design formulas are provided and Computer Aided Design techniques based on COMSOL Multiphysics® software are proposed. The virtual prototype considers the Thermo-mechanical effects due to the joule effect induced by the power which crosses the DW and the Thermal contact ...

Simulations of Negative Curvature Hollow-core Fiber - new

J. Zhang[1], Z. Wang[1], J. Chen[1]
[1]College of Optoelectronic Science and Engineering, National University of Defense Technology, Changsha, Hunan, China

COMSOL Multiphysics® software was used to simulate and analyze the transmission attenuation spectra of the negative curvature hollow-core fiber (NCHCF) over the wavelength from 2.7 μm to 4.2 μm. The effect of thickness of capillaries and the effect of the distance between the capillaries on confinement loss spectra were studied, which agreed well with the high-loss and low-loss bands predicted ...

Studying Crosstalk Trends for Signal Integrity on Interconnects using Finite Element Modeling

J. Grover[1], Dr. A. Gupta[1]
[1]Birla Institute of Technology and Science, Pilani-Pilani Campus,Rajasthan ,India

In high-speed digital design, strong electromagnetic coupling exists between adjacent transmission lines. This manifests itself in the form of crosstalk voltage induced on either line. Crosstalk is modeled in terms of capacitance and inductance matrices which are extracted using COMSOL Multiphysics®. Further, trends of crosstalk are observed with variations in dielectric constant of substrate, ...

Frequency Response Modeling of Inductive Position Sensor with Finite Element Tools - new

A. K. Palit[1]
[1]LE GmbH, Espelkamp, Germany

Position sensors have several applications in the automotive sector. Some of the common examples include automatic gear shifter module, seat position adjustment and accelerator-pedal position modules etc. Because of extreme weather condition, such as dust, humidity and moisture and fluctuation of temperature and wide operating temperature range. A non-contact type of inductive position sensor ...

FEM Based Design and Simulation Tool for MRI Birdcage Coils Including Eigenfrequency Analysis

N. Gurler[1], Y. Ziya Ider[1]
[1]Department of Electrical and Electronics Engineering, Bilkent University, Ankara, Turkey

Designing a Radio Frequency (RF) birdcage coil used in Magnetic Resonance Imaging (MRI) at high frequencies where the wavelength is comparable with the coil dimensions is a challenging task. Before construction of the coil, not only calculating the capacitance value which is necessary for the coil to resonate at the desired frequency but also geometrically modeling the coil in a 3D simulation ...

Enhancement of Terahertz Emission by AuGe Nanopatterns

H. Surdi[1], A. Singh[1], S. S. Prabhu [1]
[1]Tata Institute of Fundamental Research, Homi Bhabha
Road, Mumbai,India

Since the advent of Terhertz(THz) technology, improving the THz emission power has been one of the major research goal. One of the methods to increase the THz emission power is to increase the coupling of excitation laser light to the dielectric substrate.The field of nano-plasmonics exploits light-matter interactions at nanometer scale. With the help of metallic nano-structure at metal ...

Periodically Poled Lithium Niobate Waveguides for Quantum Frequency Conversion - new

J. Toney[1], J. Retz[1], V. Stenger[1], A. Pollick[1], P. Pontius[1], S. Sriram[1]
[1]SRICO, Inc., Columbus, OH, USA

This paper presents techniques for modeling annealed proton exchange (APE) and reverse proton exchange (RPE) waveguides in periodically poled lithium niobate for application to optical frequency conversion. A combination of time-dependent diffusion modeling and electromagnetic mode analysis using the RF module are used to predict the relationship between the poling period and the second harmonic ...

Extraction of 13.56 MHz NFC-Reader Antenna Parameters for Matching Circuit Design

Prof. Dr.-Ing. habil. A. K. Palit [1],
[1] ZF-Lemfoerder Electronic GmbH, ZF-Friedrichshafen AG. Group, Espelkamp, Germany

Introduction: RFID system uses a Transponder and the near field communication (NFC) antenna and a matching circuit (Figure-1) in which at least latter two must be optimally designed for a higher efficiency. Typically, RFID antennas are flat inductive coils with 2 to 4 turns and are printed directly on the PCB. The larger antenna size implies larger operating distance whereas, the number of ...
