Esaote SpA, Florence, Italy
Pulse-echo FEM simulation is seldom found in literature for ultrasound imaging array probes, since the complete modeling of such device is extremely complicated. Nevertheless, the 2D FEM described in the present work was successful, thanks to the following design procedure (see figure): Two piezoacoustic models were employed, one for transmission of the pressure wave into the acoustic domain, ...
C. Van der Woude, and S. Narasimhan
University of Waterloo, Waterloo, ON, Canada
This paper presents a study of a wind turbine subjected to wind and seismic loading, carried out using COMSOL Multiphysics. The dynamic properties and response of wind turbine structures are of interest, as recent developments in wind energy have led to the design and construction of increasingly large and flexible turbine structures. A typical turbine structure model was created in COMSOL and ...
U. Vogel , M. Spindler , S. Wege , T. Gemming
 Leibniz Institute for Solid State and Materials, Dresden, Germany
In this work, we seek to simulate SAWs for a better understanding and to benchmark the currently available cloud computing possibilities of COMSOL Multiphysics® software. By using the MEMS module we demonstrate 3D models with reduced geometry to achieve principle information about the wavefield. For a benchmark, a high-speed workstation with limited memory (RAM) is compared to the most potent ...
A. Bonomo, M. Isakson
Applied Research Laboratories, The University of Texas at Austin, Austin, TX, USA
COMSOL Multiphysics® is used to address the problem of acoustic scattering from one-dimensional rough poroelastic surfaces. The poroelastic sediment is modeled following the Biot-Stoll formulation. The rough surfaces are generated using a modified power law spectrum. Both monostatic and bistatic scattering strengths are calculated. These results are compared with more conventional scattering ...
R. Magalotti
 B&C Speakers, Bagno a Ripoli, Italy
Loudspeaker drivers are energy transducers: their main goal is to efficiently convert electrical energy to acoustic energy (sound), through the movement of mechanical parts. As such, they are prime candidates for the application of multiphysics methods and tools. The talk will outline the growing set of tools that COMSOL Multiphysics® software puts in the hands of the loudspeaker designer; ...
R. Haettel, A. Daneryd, M. Kavasoglu, C. Ploetner
ABB Corporate Research, Västerås, Sweden
ABB Transformers, Varennes, QC, Canada
Today, low noise is a mandatory feature for power transformers to comply with customer specifications and environmental regulations. Therefore, it is crucial to develop sound prediction tools with sufficient accuracy to avoid overkill margins in design and costly modifications after transformer completion. The paper will focus on core noise which is a typical multiphysics phenomenon involving ...
Simulation of Acoustic Energy Harvesting Using Piezoelectric Plates in a Quarter-Wavelength Straight-Tube Resonator
B. Li, J.H. You
Southern Methodist University, Dallas, TX, USA
An acoustic energy harvesting mechanism at low frequency (~200 Hz) using lead zirconate titanate (PZT) piezoelectric cantilever plates placed inside a quarter-wavelength straight-tube resonator has been studied using COMSOL Multiphysics 4.3 and compared with experimental data. When the tube resonator is excited by an incident wave at its acoustic eigenfrequency, an amplified acoustic resonant ...
D. Cinanni ,
 Ciare S.r.l., Italy
Today a horn driver developing is still time and cost consuming. In addition compression driver behavior depends by the horn profile. In this study is proposed a new technique to model a combination of an existing compression driver and a virtual horn, in order to predict the horn driver acoustic behavior. This procedure comprises compression driver measurement on a Plane Wave Tube and horn ...
A. Arevalo , D. Conchouso , D. Castro , I. G. Foulds ,
 Computer, Electrical, & Mathematical Sciences & Engineering, King Abdullah University of Science and Technology, Thuwal, Saudi Arabia
 The University of British Columbia, School of Engineering, Vancouver, BC, Canada
The growth of the electronics industry demand better components for the electronic systems. Such components need to be improve to keep up with the evolution of the digital era. The loudspeaker design has not been changed for almost a century [1-5]. The acoustic transducer is the last analogue component needed for a true digital audio system. We want to validate the feasibility of using an ...
Acoustic Field Comparison of High Intensity Focused Ultrasound Using Experimental Characterization and Finite Element Simulation
J. L. Teja, A. Vera, L. Leija
Department of Electrical Engineering, Cinvestav-IPN, Mexico D.F., Mexico
High Intensity Focused Ultrasound (HIFU) is used as a noninvasive technique of tissue heating and ablation for different medical treatments. This paper presents a quantitative comparison of HIFU acoustic fields experimentally obtained versus simulated acoustic fields. Acoustic field characterization was realized in two HIFU transducers using water as a propagation medium. Also, simulations were ...
