Calculating Thermodynamic Properties for Liquids and Gases

Ed Fontes December 26, 2017
Share this on Facebook Share this on Twitter Share this on Google+ Share this on LinkedIn

You can easily describe composition- and temperature-dependent fluid properties using the thermodynamic properties database, available as of version 5.3a of the COMSOL Multiphysics® software. For reacting systems, the database computes enthalpy of formation and enthalpy of reaction. For fluid flow and heat and mass transfer, the database can compute viscosity, density, heat capacity, thermal conductivity, and diffusivity of liquids and gases. For systems with several phases, the thermodynamic properties database computes the composition of the phases at equilibrium.

Adding Thermodynamic Models via the Built-In Database

Gas and liquid solutions that consist of mixtures of chemical compounds (species) have properties that depend on both composition and temperature. We need accurate descriptions of these properties to solve fluid flow problems with heat and mass transfer as well as reacting flow problems. These descriptions are based on thermodynamic models for properties such as heat of reaction, heat of formation, heat capacity, viscosity, density, thermal conductivity, and diffusivity.

A model of an engine coolant mixture.
This model shows how the composition of a coolant mixture affects the boiling point, density, viscosity, thermal conductivity, and heat capacity of an internal combustion engine.

For systems consisting of several phases, thermodynamic models are able to describe the composition of the phases at equilibrium. For example, for flash calculations, thermodynamic models can compute the composition of a liquid mixture at equilibrium with its vapor phase.

The Chemical Reaction Engineering Module as of COMSOL® software version 5.3a contains a new thermodynamic properties database with parameters and functions for a vast range of thermodynamic models and properties.

For gas mixtures, the following thermodynamic models are available:

  • Ideal gas
  • Peng-Robinson
  • Peng-Robinson (Twu)
  • Soave-Redlich-Kwong
  • Soave-Redlich-Kwong (Graboski-Daubert)

For liquid mixtures and vapor-liquid mixtures, these additional models are available:

  • Chao-Seader (Grayson-Streed)
  • Wilson
  • NRTL
  • Regular solution
  • Extended regular solution
  • Ideal solution

We are going to explore the functionality in the new thermodynamic properties database using three different examples. The first example deals with the calculation of fluid properties for nonisothermal flow. The second example is a model of a tubular reactor, where in addition to transport properties, chemical reactions are also taken into account. The last example studies a distillation process, where the thermodynamic properties database is used to calculate the liquid-vapor equilibrium (flash calculations), including condensation and evaporation.

Simulating Conjugate Heat Transfer in a Water-Glycol Mixture

The first example is a model of conjugate heat transfer in a four-cylinder combustion engine. In cold climates, the coolant liquid that flows inside the channels in the engine block is a mixture of glycol and water.

A COMSOL Multiphysics model of a four-cylinder engine.
Temperature in the cooling channels inside the engine block in a four-cylinder engine.

The properties of the coolant — such as heat capacity, thermal conductivity, density, and viscosity — depend on the composition of the mixture and on temperature. In this case, the thermodynamic model is the UNIFAC VLE. An ideal model is used for the thermal conductivity of the mixture.

The plot below shows the thermal conductivity as a function of the mole fraction of glycol in the mixture and of temperature. We can see that the thermal conductivity for a mixture of a mole fraction of glycol of 0.1 is 25–30% larger than that of a mixture of 0.5 mole fraction of glycol at any given temperature. The variations in temperature from -10°C over a range of 110°C is around 20% for any given composition (from 0.1 to 0.5 mole fraction of glycol).

A plot of the thermal conductivity in a glycol-water mixture.
Thermal conductivity in the glycol-water mixture as a function of composition and temperature. The contour lines show values scaled by the thermal conductivity of water at 20°C.

Modeling Transport and Reactions

For chemical engineers, the thermodynamic properties database also allows for the modeling of reacting systems, where the heat of reaction and the enthalpy for phase transfer reactions can be calculated automatically from the database. The figure below shows the concentration of the reactants and products as well as the temperature in a tubular reactor for the thermal hydrodealkylation (HDA) of toluene, in which benzene is the desired product. Two reactions occur in the reactor. The first reaction is the desired irreversible dealkylation of toluene:

A chemical reaction: irreversible dealkylation of toulene.

This is followed by the by-reaction, which is the reversible production of biphenyl:

A chemical by-reaction: reversible production of biphenyl.

The model describes how the feed of hydrogen and the control of the temperature in the reactor can also be used to control the production of the desired product, benzene. For example, the figure below shows that after the axial position around x = 0.4, the concentration of the desired product increases to a very small extent. Most of the toluene in the remaining length of the reactor is converted to the unwanted biphenyl.

A plot showing the concentration and temperature in a tubular reactor.
Concentration and temperature in a tubular reactor for benzene production as a function of the axial position.

A better yield for the desired benzene product is obtained if hydrogen is fed continuously through the reactor walls using a membrane. This is shown in the figure below, where toluene is almost completely converted with a lower production of biphenyl at the same time.

A plot showing the concentration and temperature in a tubular reactor when hydrogen is fed through the walls.
Concentration and temperature in a tubular reactor for benzene production as a function of the axial position. The reactor is equipped with a hydrogen permeable membrane that, by keeping a decent hydrogen concentration, reduces the production of biphenyl.

The amount of work that is required for this nonisothermal transport-reaction model would be substantial (days) without the use of the thermodynamic properties database, not to mention the time it would take to find the thermodynamic models and the data used for these models. With the thermodynamic properties database, the model can be defined in a matter of minutes.

Flash Calculations for Modeling a Distillation Column

The third example models a distillation column, where a liquid mixture of water and ethanol is fed into the column between the stripping and the rectifying sections. Liquid from the feed runs down the column and is heated and partially vaporized in the reboiler. Normally, some of the liquid in the reboiler is continuously removed as the bottom product. The vapor generated in the reboiler rises up toward the top of the column, where it is condensed in the condenser. Some of the condensed liquid in the condenser is normally removed as the overhead product or distillate. The remainder of the condensed liquid is sent back down the column as reflux.

A diagram of a distillation column.
The distillation column where the feed is placed near the middle, while the reboiler is at the bottom and the condenser at the top.

The thermodynamic model used for this example is the NRTL model. The resulting compositions of the vapor and liquid phases along the height of the column are shown below. We can see the little crinkle in the liquid phase composition curve at the position of the feed, at a distance of 1.2 m from the bottom. The curves show that we cannot obtain a separation that is above an ethanol mole fraction of 0.85; i.e., at this stage, the composition of the vapor and liquid phases are the same.

A 1D plot of the vapor and liquid phase composition in a distillation column.
Vapor and liquid phase composition as a function of the distillation column height.

Linking the Thermodynamic Properties Database with the Reaction Engineering Interface

The thermodynamic properties database is also implemented in such a way that you can apply its functionality to existing reaction engineering models. If we already have an existing reaction engineering model, or if we decide to define an isothermal system in the first stage, which does not require the use of the thermodynamic database, we can always expand the model later to include thermodynamics.

The image below shows the definition of a thermodynamic property package for the reformation of methane. In this case, the reaction engineering model is already available for an isothermal system. When we add the thermodynamic property package, we select the species that are relevant to our system; that is, we add the compounds from the database. We also select the thermodynamic model that we want to use to describe our mixture.

An annotated screenshot showing the definition of a thermodynamic property package in COMSOL Multiphysics.
The settings for a thermodynamic property package, with the list of selected chemical species (compounds) and the thermodynamic model for the mixture.

Once we have defined our thermodynamic property package, we can link it to the Reaction Engineering interface by matching the species already defined in the interface with the species defined in the thermodynamic property package.

An annotated screenshot showing the Reaction Engineering interface in COMSOL Multiphysics.
When we have defined a property package, we can match the chemical species in this package with the chemical species in an already existing reaction engineering model.

Once the linking is done, the reactor model can be run for the species and energy balances with a full description of the thermodynamics and transport properties of the system originating from the database.

Concluding Remarks

The new thermodynamic properties database can be used over a wide range of applications, including:

  • Fluid flow and nonisothermal flow, where the properties of the fluid depend on composition and temperature, but where the system does not involve chemical reactions
  • Nonisothermal reacting flow, where transport properties, heat capacity, and heat of reactions are calculated from the thermodynamic model
  • Liquid-vapor, liquid-liquid, and liquid-liquid-vapor phase equilibrium calculations for the composition of mixtures, including transport properties and thermodynamic models for the different phases

Next Steps

Try out the examples reviewed in this blog post, which are available in the Application Gallery:
