LiveLink™ for MATLAB®
Interface MATLAB® with COMSOL Multiphysics® via LiveLink™ for MATLAB®
Example illustrating the modeling of a spring-loaded centrifugal governor. All plots that can be shown in COMSOL Multiphysics® can also be shown as MATLAB® figures.
Integrate COMSOL Multiphysics® with MATLAB® Scripting
Seamlessly integrate COMSOL Multiphysics® with MATLAB® to extend your modeling with scripting programming in the MATLAB environment. LiveLink™ for MATLAB® allows you to utilize the full power of MATLAB and its toolboxes in preprocessing, model manipulation, and postprocessing:- Enhance your in-house MATLAB code with powerful multiphysics simulations
- Base your geometry modeling on probabilistic or image data
- Perform arbitrary statistical analysis on simulation results
- Use multiphysics models together with Monte Carlo simulations and genetic algorithms
- Export COMSOL models on state-space matrix format for incorporating into control systems
- Call MATLAB functions from the COMSOL Desktop®
MATLAB is a registered trademark of The MathWorks, Inc. All other trademarks are the property of their respective owners. For a list of such trademark owners, see http://www.comsol.com/tm. COMSOL AB and its subsidiaries and products are not affiliated with, endorsed by, sponsored by, or supported by these trademark owners.
Product Features
- Use MATLAB® as a scripting tool to set up and solve your COMSOL models
- Import/export data from/to the MATLAB® workspace
- Interface in the COMSOL Desktop® environment enables the use of MATLAB® functions while modeling
- A suite of dedicated functions for ease-of-use
Application Areas
- Preprocess data, such as images and experiments, to include in your models
- Extract data from your models for customized postprocessing and visualization
- Manipulate your models from the command line or script to parameterize the geometry, physics, or the solution scheme
- Use MATLAB®'s GUI building tools to create custom-made graphical user interfaces for your models for deployment to users in your organization
- Define model settings using MATLAB® functions
- Wrap the solution process in a loop where you can: handle different cases in the solution process; stop and restart a solution based on a specified solution; formulate custom initial conditions
Supported File Formats
| File Format | Extension | Import | Export |
|---|---|---|---|
| MATLAB®: Function | .m | Yes | No |
